KEF THX Meta Rectangle In-Wall Speaker with 4x 6.5" (LF), 1x 6.5"

Model: CI5160RLM-THX

KEF THX Meta Rectangle In-Wall Speaker with 4x 6.5" (LF), 1x 6.5" (MF), 1x 1" (HF) Drivers. Uni-Q with Vented Aluminum Dome and Metamaterial Absorption Technology. Sold Individually.

Ultra-high-performance architectural speaker with MAT™

The Ci5160RLM-THX is an in-wall architectural speaker featuring the 12th generation Uni-Q driver array with KEF’s groundbreaking Metamaterial Absorption Technology (MAT™), refined to maximise its full potential and proudly carries the THX Certified Ultra designation. Together with four 6.5” hybrid aluminium bass drivers, it delivers the most dynamic audio experience for home theatres.





Specifications:

  • Nominal Impedance: 4Ω
  • Sensitivity (2.83V/1m): 89dB
  • Frequency Response (±6 dB) open-backed: 40 - 28kHz
  • Frequency Range (-10 dB): 32 - 45kHz
  • Nominal Coverage (degrees): 150°
  • Crossover Frequency: 640Hz, 2.6kHz
  • Drive Units:
    • LF: 4 x 160mm (6.5in.)
    • MF: 160mm (6.5in.) Uni-Q
    • HF: 25mm (1in.) vented aluminium dome with Metamaterial Absorption Technology1
  • Recommended Amplifier Power: 50 - 350 W
  • Recommended High-pass Filter (Hz): 35Hz - 80Hz
  • Product External Dimensions (H X W X D): 1070 x 230 x 105.7mm (42.13 x 9.06 x 4.16in.)
  • Cut-out Dimensions (H X W): 1052 x 209mm (41.42 x 8.23in.)
  • Net Weight: 18.7kg (41.1lbs.)
  • Mounting Depth From Surface: 99mm (3.9in.)
  • Max SPL (dB): 110dB
  • Certification: THX® Certified Ultra
  • Wall Thickness (Maximum): 40mm (1.58in.)
  • Wall Thickness (Minimum): 6mm  (0.24in.)
