EDIMAX Industrial 5-Port Gigabit PoE+ DIN Rail Switch. 4 x Gigabit

Model: IGS-1105P

EDIMAX Industrial 5-Port Gigabit PoE+ DIN Rail Switch. 4 x Gigabit Ethernet Ports, 1 SFP Uplink Port. PoE up to 200m @10Mps. QoS 802.1p for Video & Voice Traffic Priority Inputs, Surge Protection, IP30

FEATURES:

4 Gigabit Ethernet PoE+ ports and 1 SFP uplink port
6KV Surge protection to avoid damage to the switch and connected devices
Power redundancy by providing Dual-DC power inputs to ensure stable and reliable network service
P-fail relay with alarm and notification when an event of power failure occurs
Supports QoS 802.1p for video & voice traffic priority
Wide operating temperature range of -20°C~+70°C
IEEE 802.3af/at PoE compliant supports up to 30W per port (power budget: up to 120Watts)
Guaranteed PoE long distance to 200 meters
Power back feed protection to avoid damaging the PoE ports
Flexible deployment with DIN-Rail mounting kit and wall-mount feature
IP30-rated, fanless rugged industrial design for harsh environments

6KV Surge & Power BackFeed Protection

Supports 6KV lightning surge and power backfeed protection for connected devices from non-standard power sources. Further avoiding damage done to the switch and connected devices.

Wide Temperature Range

The industrial switch operates with a wide temperature range from -20°C ~ 70°C for industrial network deployment in extreme hot and freezing environments.

PoE Long Range Guaranteed 200M

Provides the PoE long-range solution with a guarantee of 200 meters ideal for surveillance and parking lot applications.

Reliable Power Redundancy

Supports power redundancy with three power inputs to decrease unexpected risk and ensures stable and reliable network service quality.

QoS with Improved Traffic Efficiency

Supports 802.1p QoS for ensuring first priority voice and video traffic for reduced package loss, lower latency and jitter on the network.

Flexible DIN-Rail & Wall Mount

The switch is designed with flexibility for DIN-rail mounts or wall-mount deployment.
