HARDWARE
Ports	8 x RJ45 10/100/1000Base-T Gigabit Ports
Button	Reset Button
LED Indicators	Per Port : Link/Act Per Unit : Power
Power Input	External Power Supply (DC 5V/1A)
Fan	Fanless Design
Dimensions	155 x 85 x 26 mm
Weight	325g
PERFORMANCE
Switching Capacity	16Gbps
MAC Address	4K
Jumbo Frames	9KB
Transmission Method	Store and Forward
Filtering / Forwarding Rates	Max. 11.9Mpps • 1000Mbps port - 1,488,000pps • 100Mbps port - 148,800pps • 10Mbps port - 14,880pps
SMART FEATURES
Quality of Service (QoS)	Port-based QoS, IEEE802.1p QoS, 4 Priority Queues, Scheduling Algorithm • WFQ (Weighted Fair Queue) • Strict Priority
VLAN	Up to 8 VLANs and 4096 VLAN IDs 802.1Q Tag-based VLAN
Port Trunking	IEEE 802.3ad LACP Trunk-Static Trunk up to 8 Trunk Groups
Port Mirroring	Port Mirroring both on Ingress and Egress Traffic
IGMP Snooping	IGMP Snooping v1/v2/v3 Block Unknown Multicast Traffic Multicast Groups: 128
Loop Detection	Loop Detection Loop Prevention
Security	Broadcast Storm Control
Management	User Interface: Web-based Management User Account: Login Account Configuration Firmware Upgrade: Firmware Upgrade by WEB
OTHERS
Standards	IEEE 802.3 10BaseT Ethernet IEEE 802.3u 100BaseTX Fast Ethernet IEEE 802.3ab 1000BaseT Gigabit Ethernet IEEE 802.3x Full-duplex and Flow Control IEEE 802.3ad Link Aggregation Control Protocol (LACP) IEEE 802.3az Energy Efficient Ethernet IEEE 802.1Q VLAN IEEE 802.1p Quality of Service (QoS)
Environmental Condition	Temperature: Operating: 0 ~ 40℃ (32°F ~104°F) Storage: -40 ~ 70℃ (-40°F ~158°F)	Humidity: Operating: 10 ~ 90% (Non-condensing) Storage: 5 ~ 90% (Non-condensing)
Certifications	CE, FCC, BSMI

Maximum performance, actual data rates, and coverage will vary depending on network conditions and environmental factors.
*Actual viewing resolution and frame rate of network cameras depend on connection speed.
*Product specifications and design are subject to change without notice.
